RcJunkie TLR 5b

[RcJunkie13]

wonder if its possible to do a closed loop cooling system using boat parts

Yeah cuz this heat thing is really getting in my nerve. Oh and my carb is leaking a little from the shaft



[crucialRC]

How much did you open the body? What oil mix ratio you running?



[RcJunkie13]

How much did you open the body? What oil mix you running?

Running 25:1 or 28:1 can’t remember
Body:

also cut out the front window and vents



[crucialRC]

Still not enough cutting bro. Gotta get that pipe uncovered. I also made a heat deflector similar to my mcd rr5. You can actual buy one from cardinalracing.com.



[RcJunkie13]

Link/pic?



[crucialRC]

https://cardinalracing.com/products/air-flow-set



[RcJunkie13]

Cool thanks, also the kill button just came unplugged from the coul



[RcJunkie13]

Ok so I have an idea, and I know I’ve been not wanting to do this the whole time but what if the air filter stuck out of the body, the body is hot underneath, like if I touch my metal servo horn it’s hot. So the engine is prolly I taking hot air causing a lack of performance and a hot running engine. When the body is taken off then it is in taking the outside temp air. Make sense?



[Rep732]

Air cooled engines need air passing through the cooling fins on the head to help dissipate the heat...if your body doesn't have enough flow through it yes its hurting all aspects and moving the filter to the outside of the body wouldn't solve your problem....

Also your not putting the advise you've been given here a try.... Lance mentioned a heat shield.. have you tried that? Did you cut more holes in the body as was already said to do. Go buy 1" wide header wrap and wrap the header... if you go that way you must soak the header wrap in HOT water for about 15 minutes so it will contour to the pipe better and when it dries it will be tight... becareful of the stainless steel zip ties in the kit they will make you bleed



[RcJunkie13]

Yeah I got u but how much more can I really open it up, and the minor things I may do I fell can hardly do much at all, There is little left to do IMO. I need a way to force more air I think



[Rep732]

Looking at how these engines work and using the flywheel to your advantage its a cooling fan as well. So looking at the back of the pullstart that side is the suction side and the clutch side is where the outlet is. There has to be a simpler way to do this but you need to get fresh outside air to be drawn in toward that fan and you should be bringing Temps down... or 2nd solution is buy a computer or rc motor cooling fan and mount it to the body so it can draw cooler air into the body and use the reciever battery to run the fan.



[Seandonato73]

Or just open the body up like everyone else that has one.... not rocket science here. Air in air out.



[crucialRC]

Pretty much I've given you the advice bro. I've gone thru this issue myself and even have videos of it on my YT channel. I was confused with it as well. Check out my old videos of my L5B, same overheating issues. You have to open that shell up. It will be the only thing that will help.



[RcJunkie13]

Hey guys does the thumb screw ps things work with the end bleed pipe?



[Z.hb71]

it works with deez nutz



[Rep732]



[RcJunkie13]

I just wanna feking answer



[Z.hb71]

I just wanna feking answer

Good luck.



[RcJunkie13]

Good luck.

But why



[Z.hb71]

You know why.
