crucialRC said:
I didn't see where they let you them know what gearing your going with. What gearing you going with? I also didn't see a taller gear avail than the 18/23, just like the t90. Maybe I missed it.
Click to expand...
The vertigo has 6 gearing options I’m not sure what gears come with it as I didn’t see where the mention it either. It just says their “recommended” gearing, based on the motor you choose maybe? From vertigo site they say they have 18/23, 19/22, and 20/21 which can be bought in those pairings and then swapped around for different ratios.

crucialRC said:
I didn't see where they let you them know what gearing your going with. What gearing you going with? I also didn't see a taller gear avail than the 18/23, just like the t90. Maybe I missed it.
Click to expand...

correct me if I’m wrong, but wouldn’t 18/23 be the shortest gear? The 20/21 would be the tallest right? Because a biggerpinion means more speed and a smaller spur means more speed, right?

JT3 said:
correct me if I’m wrong, but wouldn’t 18/23 be the shortest gear? The 20/21 would be the tallest right? Because a biggerpinion means more speed and a smaller spur means more speed, right?
Click to expand...
The 18/23 can also be used as 23/18 (with the 23 as the pinion). So the same tallest gear as the T90. I added a note to my order requesting the 23\18 gearing. We will see if that's what they send with it. You can also add if you want anodizing in the notes. Once payment for the engine was received Detroit Performance sent me a separate payment request for the anodizing.

cardarear said:
The 18/23 can also be used as 23/18 (with the 23 as the pinion). So the same tallest gear as the T90. I added a note to my order requesting the 23\18 gearing. We will see if that's what they send with it. You can also add if you want anodizing in the notes. Once payment for the engine was received Detroit Performance sent me a separate payment request for the anodizing.
Click to expand...
Ah ok. I didn’t really you could swap the spur into the pinion position.

as far as anodizing. ?


Attachments

  • 0A6F10E2-BDE0-4FE9-B94D-4DC1E5C6290E.jpeg
    46.5 KB · Views: 5
JT3 said:
Ah ok. I didn’t really you could swap the spur into the pinion position.

as far as anodizing. ?
Click to expand...
Nice. Keeping it a secret, I see.
crucialRC said:
The tallest gear is the 18/23. The pinion is 23. Idler gear 18. The "spur" or actually slipper gear is not changed. Im not sure about this use one idler and one pinion switch up/combo cause you cannot change the mesh like on a Losi. Gear placements are set. Maybe you can but never heard of it.
Click to expand...
I believe the mesh is not an issue becaue all gearing combinations add up to a total of 41 no matter which orientation you choose.

crucialRC said:
The tallest gear is the 18/23. The pinion is 23. Idler gear 18. The "spur" or actually slipper gear is not changed. Im not sure about this use one idler and one pinion switch up/combo cause you cannot change the mesh like on a Losi. Gear placements are set. Maybe you can but never heard of it.
Click to expand...
Could you expand on this a bit for me? I came from electric so I’m only familiar with having a pinion on the motor and a “spur” corrected to the drivetrain.

JT3 said:
Could you expand on this a bit for me? I came from electric so I’m only familiar with having a pinion on the motor and a “spur” corrected to the drivetrain.
Click to expand...
Sorry guys I was out running my 8ight-T 4.0? I'm new to it also and actually still learning. Even the losi isn't like this. There is a pinion, idler gear(at least that's what I call it. Lol) and a spur/slipper gear. See below. The slipper is in-between the front and rear center out drive cups and the idler gear marries the pinion to the slipper.
Screenshot_20200606-175043_Video Player.jpg20200504_190317.jpg

Last edited:
Your not gonna be able to just flip the two gears around like you think with out being able to set the mesh, that's why they sell them as a matched set. The larger gear will most likely be too tight on the slipper set up. If you can even get it on.

Seandonato73 said:
Your not gonna be able to just flip the two gears around like you think with out being able to set the mesh, that's why they sell them as a matched set. The larger gear will most likely be too tight on the slipper set up. If you can even get it on.
Click to expand...
Hmm every answer I get just brings new questions haha. If they only sell 3 matching sets how can they claim to have 6 hearings available?

From vertigo: “Pinion gear and mating gear sold separately in pairs, these pairs offer a total of 6 different gearing options.”

crucialRC said:
I didn't see where they let you them know what gearing your going with. What gearing you going with? I also didn't see a taller gear avail than the 18/23, just like the t90. Maybe I missed it.
Click to expand...
I just shot John an email to ask about what gearing comes with it since all the site says is “our recommendation” will let y’all know what I find out.
